Standard Shipping - Will ship within 24-72 business hours (In Stock)

___________________________________________________________

Weight Capacity Top Speed Turning Radius Range Product Weight
300 lbs 4 mph 23.5 12 miles 160.5 lbs

New product

The Jazzy Elite ES delivers a reliable blend of power, performance and style. In-line, front-wheel drive technology gives the Elite ES excellent stability and maneuverability for solid performance indoors and out.

Read whole description

Limited special offer

$3,529.00

Before $5,750.00

  • 18" x 18" x 20" High Back Limited Recline
  • 18" x 18" Comfort High Back

- +

Select options for product
Seat    * Required
Footrests
Seatbelt
Joystick Mounting Hardware    * Required
Delivery Options
Help me choose
Armrest Style    * Required
Accessories
No, Thanks

No, Thanks
Crutch & Cane Holder

Crutch & Cane Holder
[Add $98.00]
Foot Platform Bracket (Height Adjustable)

Foot Platform Bracket (Height Adjustable)
[Add $40.00]
 1" Rubber Threshold Ramp

1" Rubber Threshold Ramp
[Add $85.00]
FREE Cup Holder ($20 VALUE)

FREE Cup Holder ($20 VALUE)
Large Saddlebag

Large Saddlebag
[Add $53.00]
Oxygen Holder

Oxygen Holder
[Add $98.00]
Small Saddlebag

Small Saddlebag
Swing Away/ Elevating Heel Loops

Swing Away/ Elevating Heel Loops
[Add $30.40]
Walker Holder

Walker Holder
[Add $98.00]

  Quantity:
Shipping Rates
Free shipping on orders over $100 or more

BROCHURE
MANUAL
SPECS
SAFETY

Description

Pride Jazzy Elite ES Power Wheelchair delivers a reliable blend of power, performance and style. Elite ES-1 power chair is designed with in-line, front-wheel drive technology that provides it with excellent stability and maneuverability for solid performance indoors and outdoors and is designed for easy serviceability..

Features:

  • In-line, front-wheel drive technology
  • 40 amp, PG GC 3 controller
  • Simple main frame design for easy serviceability
  • Comfort high-back seat with headrest
  • Jazzy Armor controller guard to protect from daily wear and tear
  • Basic Jazzy Armor shroud decals

Specifications

Model Jazzy Elite ES
Weight Capacity 300 lbs.
Turning Radius1 23.5"
Width1 22.75"
Length1,2 34.75"
Maximum Speed3 Up to 4 mph
Ground Clearance1 .75"
Front Wheels 5" solid anti-tips
Drive Wheels 9" solid
Rear Wheels 6" solid casters
Drivetrain Two-motor, in-line, front-wheel drive
Braking System Regenerative and electro-mechanical
Suspension Type Limited
High-Back Seat (max. size) 20"W x 20"D
High-Back Seat-to-Floor Range 21.5" - 23.5"
Standard Electronics 40A, PG GC3
Battery Size (2 required) 12 volt, U-1
Standard Battery Charger 3A, off-board
Per-Charge Range3,11 Up to 12 miles
Battery Weight9 24.5 lbs. each
Weight of Heaviest Piece5 68.5 lbs.
Standard Seat Weight 43 lbs. (comfort, high-back)
Standard Seat Size 18" x 18"
Warranty 5-year limited warranty on frame;
13-month limited warranty on electronics;
13-month limited warranty on drive motors
Notes 1Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of + or - 3 %. Dimensions listed are for power base only. Overall measurements will vary based on seating and accessory selections.
2Without front riggings.
3Varies with user weight, terrain, battery type, battery condition and tire pressure.
5Does not include seat or battery weights.
9Battery weight may vary based on manufacturer.
11Tested in accordance with ANSI/RESNA, WC Vol. 2, Section 4 and ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance. Testing conducted at maximum weight capacities. This specification can be subject to a variance of +10%, -5%.

 POWER CHAIRS/SCOOTERS

WARNING: This product can expose you to chemicals including lead and lead components, which is [are] known to the State of California to cause cancer or birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov/furniture.

Weight Capacity 300 lbs.
Product Weight 161 lbs
Heaviest Piece 69 lbs
Battery Weight 25 lbs. (each)
Battery Type U-1
Maximum Speed 4 mph
Drive Range 12 Miles
Turning Radius 24"
Seat Width 18" or 20"
Seat Depth 18" or 20"
Seat Type Captain Seat
Overall Length 34.75"
Overall Width 22.75"
Ground Clearance 1"
Drive Type Front Wheel Drive
Front Wheel Size 9"
Rear Wheel Size 6"
Joystick Options Adjustable Left or Right
